9 Of The Biggest ISRO’s Future Missions

[Estimated read time: 5 minutes]

Indian Space Research Organization (ISRO) has had numerous remarkable milestones since its inception in 1969. Their primary vision is to “harness space technology for national development while pursuing space science research and planetary exploration”. They have time and again proved that they completely stand by their vision and their recent achievements have created a standard par excellence for other space agencies as well.

ISRO is best known for their cost effective missions. They majorly work on interplanetary projects, lunar missions and Earth satellites. The space agency’s long term plans include undertaking over 50 missions and deploying 500 satellite communications transponders before 2020. We are listing some of those future missions that might take the Indian space agency to the new heights.

9. RLV-TD

Reusable Launch Vehicle – Technology Demonstrator project is a first step towards realizing a Two-Stage-To-Orbit re-usable launch vehicle. It will act as a flying bed to evaluate technologies like autonomous landing using air-breathing propulsion, powered cruise flight and hypersonic flight.

The rocket has a nose cap, fuselage, double delta wings, twin vertical tails and symmetric active control surfaces called Elevons and Rudder. Using these kind of technologies would reduce the launch cost by a factor of 10. However, the selection of materials like special alloys, composites and the crafting of its parts is quite a complex process and requires highly skilled manpower.

8. RISAT 1A

RISAT 1A is a remote sensing satellite, third in a series of RISAT satellites, being developed by ISRO. It will be a land-based mission that will perform terrain mapping and analyze ocean, land and water surface for soil moisture.

The satellite will be equipped with Synthetic Aperture Radar, which can be used for Earth observation irrespective of the light and weather conditions. It will operate at 5.35 GHz in C band. The satellite is planned to be launched on PSLV in 2019.

7. GSAT 11

GSAT 11 is a geostationary communication satellite based on the new I-6K Bus, which will carry 40 transponders in the Ku-band and Ka-band frequencies. They are 3-6 times more powerful than that used in existing Indian communication satellites and capable of providing 12 Gbit per second throughput.

It will weigh 5.7 tonnes – more than twice as much as the biggest Indian satellite in orbit now. The whole project is allocated a total budget of $77 million. The satellite is planned to be launched by a GSLV Mk3 rocket in early 2018. The payloads will have 40 high power Ku, Ka band transponders that will cover the entire country including Andaman and Nicobar Islands. Moreover, the satellite will be configured with 2-sided big solar panels generating 11 KW of power.

6. GSLV III

The Geosynchronous Satellite Launch Vehicle Mark III is designed to launched satellites into geostationary orbit. It features cryogenic third stage and higher payload capacity than the GSLV II. ISRO successfully tested the CE-20 engine on 19 February 2017. The first C25 stage will be used on the GSLV III D-1 in the late May 2017 launch. It will put GSAT 19E communication satellite in the orbit. Moreover, the first manned flight would take place after 2020.

There is a proposal to include SCE-200 (liquid fueled rocket engine) in GSLV III in order to boost its payload capacity to 6 tonnes to Geostationary transfer orbit.

5. Avatar

‘Aerobic Vehicle for Transatmopheric Hypersonic Aerospace TrAanspoRtation‘ is a conceptual single-stage reusable spacecraft capable of horizontal takeoff and landing. It is primarily developed for low cost military and commercial satellite space launchers, as well as for space tourism. It is projected to weigh 25 tons, of which 60 percent of that mass would be liquid hydrogen fuel.

The first scaled down tests were performed in 2016, and the first manned Avatar spaceflight is planned for 2025. The rocket design has already been patented in India and applications for registration of the design have been filed in patent offices in China, Germany, Russia and USA.

4. Aditya

Aditya is a satellite whose aim is to study the Sun by the year 2019-20. It will be the first Indian based Solar Coronagraph that will study the Coronal Mass Ejection, Coronal magnetic field structures and evolution of the coronal magnetic field. It will provide new information on the velocity fields and their variability in the inner corona.

Around half million has been allocated as an experimental budget for the financial year 2016-17. The scope of the project has been enhanced and it is now planned to be a comprehensive space environment observatory to be placed at the Lagrangian point L1. Only ESA and NASA have successfully placed satellites at L1 point as of date.

3. Venusian Orbiter Mission

Venusian Orbiter is a proposed orbiter to Venus to study the atmosphere of the planet. If funded, it would be launched by 2020. After the mega launch of 104 satellites into the space in one go, finance minister Arun Jaitley gave the space agency a 23% increase in its budget. The budget mentions provisions for Mission to Venus.

Michael Watkins, director of the Jet Propulsion Laboratory of NASA, said a mission to Venus is worthwhile as so little is known about that planet and NASA would be interested to partner in India’s maiden voyage to Venus. ISRO and NASA have begun studies on using electrical propulsion for powering this project.

2. Chandrayaan-2

Chandrayaan-2 will be India’s second missions to the Moon that is set to launch in the first quarter of 2018. It will have an orbiter and lander-rover module that will pick up rock and soil samples for on-site chemical analysis, and data will be relayed to Earth via orbiter. The mission is planned to be launched on GSLV Mk II (Geosynchronous Satellite Launch Vehicle) from Sriharikota Island.

Read: Top 10 Space Research Organisations in the World

Chandrayaan-2 has an allocated budget of $91 million, and because of weight restrictions the rocket will not carry any foreign payloads. The approximate lift-off mass would be 3,250 kilograms.

1. NISAR

NISAR

NASA-ISRO Synthetic Aperture Radar (NISAR) is perhaps the biggest collaboration between ISRO and NASA to develop and launch a dual frequency synthetic aperture radar satellite. It will be the world’s first satellite to use dual frequency. The aim of the mission is to analyze ice-sheet collapse, ecosystem disturbances and natural hazards like volcanoes, landslides, earthquake and tsunamis.

Read: 13 of the Biggest NASA’s Future Missions

Over $1 billion of budget has been allocated for this project. ISRO will provide a launcher, S-band synthetic aperture radar (SAR) payload, spacecraft bus and associated services. Whereas, NASA will provide project’s L-band SAR, a payload data subsystem, a solid state recorder and GPS receiver. The 3-axis stabilized satellite would weigh 2,600 kilograms and likely to be launched from India, in mid 202o.
